CPV364M4UPbFwww.vishay.comVishay SemiconductorsIGBT SIP Module(Ultrafast IGBT)FEATURES Fully isolated printed circuit board mount package Switching-loss rating includes all tail losses RoHSCOMPLIANT HEXFRED soft ultrafast diodes Optimized for high speed over 5 kHzSee fig. 1 for current vs. frequency curveIMS-2 UL approved file E78996 Designed and qualified for industrial level Material categorization: For definitions of compliance please see www.vishay.com/doc?99912 PRODUCT SUMMARYOUTPUT CURRENT IN A TYPICAL 20 kHz MOTOR DRIVEDESCRIPTIONIRMS per phase (3.5 kW total) 12 ARMSwith TC = 90 CThe IGBT technology is the key to Vishays Semiconductors TJ 125 Cadvanced line of IMS (Insulated Metal Substrate) power Supply voltage 360 VDCmodules. These modules are more efficient than comparable bipol
