Silicon FS Trench IGBT CRG60T60AK3H General Description VCES 600 V Using HUAJING's proprietary trench design and advanced Field IC 60 A Stop (FS) technology, offering superior conduction and switching 403 W Ptot TC=25VCE(sat) 1.85 V performances. RoHS Compliant. Features FS Trench Technology, Positive temperature coefficient Low saturation voltage VCE(sat),TYP=1.85V @IC=60A,VGE=15V Applications Welding Solar Inverter UPS Package Parameters Type Marking Package CRG60T60AK3H TO-247 G60T60AK3H WU XI CHI NA RE SO UR CE S HUAJ I NG MIC ROELECT R ONIC S C O. , LT D. P a g e 1 of9 2021V01 CRG60T60AK3H Absolute Maximum RatingsTC= 25 unless otherwise specified Symbol Parameter Rating Units VCES Collector-Emitter Voltage 600 V VGES Gate- Emitter Voltage V 20 Collector Current @T
