fga25n120ftd.pdf datasheet:

February 2009FGA25N120FTDtm1200V, 25A Trench IGBTFeatures Field stop trench technologyGeneral Description High speed switchingUsing advanced field stop trench technology, Fairchilds 1200V Low saturation voltage: VCE(sat) =1.6V @ IC = 25Atrench IGBTs offer superior conduction and switching perfor- High input impedancemances, and easy parallel operation with exceptional avalanche RoHS complaintruggedness. This device is designed for soft switching applica-tions.Applications Induction heating and Microvewave oven Soft switching applicationsCGTO-3PEG C EAbsolute Maximum RatingsSymbol Description Ratings UnitsVCES Collector to Emitter Voltage 1200 VVGES Gate to Emitter Voltage 25 VCollector Current @ TC = 25oC50 AICCollector Current @ TC = 100oC25 AICM (1) Pulsed Collector Current 75 AIF Diode conti
