fgh80n60fd.pdf datasheet:
November 2009FGH80N60FDtm600V, 80A Field Stop IGBTFeatures General Description High current capability Using Novel Field Stop IGBT Technology, Fairchilds new ses-ries of Field Stop IGBTs offer the optimum performance for Low saturation voltage: VCE(sat) =1.8V @ IC = 40AInduction Heating applications where low conduction and High input impedanceswitching losses are essential. Fast switching RoHS complaintApplications Induction Heating ApplicationE CCGGCOLLECTOR(FLANGE)EAbsolute Maximum RatingsSymbol Description Ratings UnitsVCES Collector-Emitter Voltage 600 VVGES Gate-Emitter Voltage 20 VCollector Current @ TC = 25C80 AICCollector Current @ TC = 100C40 AICM (1) Pulsed Collector Current @ TC = 25C 160 AMaximum Power Dissipation @ TC = 25C290 WPDMaximum Power Dissipation @ TC = 100C1
