fmm22-06pf.pdf datasheet:

fmm22-06pffmm22-06pf

Advance Technical InformationPolarHVTM HiPerFETVDSS = 600VFMM22-06PFN-Channel Power MOSFETID25 = 12APhase leg Topology RDS(on) 350m 33T1trr(max) 200ns5544T2112 ISOPLUS i4-PakTM2Symbol Test Conditions Maximum RatingsTJ -55 ... +150 CTJM 150 C1Tstg -55 ... +150 CIsolated TabVISOLD 50/60HZ, RMS, t = 1min, leads-to-tab 2500 ~V5TL 1.6mm (0.062 in.) from case for 10s 300 CTSOLD Plastic body for 10s 260 CFC Mounting force 20..120 / 4.5..27 N/lb.Features Silicon chip on Direct-Copper Bond(DCB) substrate- UL recognized packageSymbol Test Conditions Maximum Ratings- Isolated mounting surfaceVDSS TJ = 25C to 150C 600 V- 2500V electrical isolation VDGR TJ = 25C to 150C, RGS = 1M 600 V Avalanche rated Low QGVGSS Continuous 30 V
