fqd5n20 fqu5n20.pdf datasheet:

April 2000TMQFETQFETQFETQFETFQD5N20 / FQU5N20200V N-ChanneI MOSFETGeneraI Description FeaturesThese N-Channel enhancement mode power field effect 3.8A, 200V, RDS(on) = 1.2 @VGS = 10 Vtransistors are produced using Fairchilds proprietary, Low gate charge ( typical 6.0 nC)planar stripe, DMOS technology. Low Crss ( typical 6.0 pF)This advanced technology has been especially tailored to Fast switchingminimize on-state resistance, provide superior switching 100% avalanche testedperformance, and withstand high energy pulse in the Improved dv/dt capabilityavalanche and commutation mode. These devices are wellsuited for high efficiency switching DC/DC converters,switch mode power supply, DC-AC converters foruninterrupted power supply, motor control.DD G D-PAK I-PAKGSFQD Series G FQU SeriesD S SAbsoI
