IGB15N60T TrenchStop Series q Low Loss IGBT in TrenchStop technology C Very low VCE(sat) 1.5 V (typ.) Maximum Junction Temperature 175 C Short circuit withstand time 5s G Designed for frequency inverters for washing machines, fans, Epumps and vacuum cleaners TrenchStop technology for 600 V applications offers : - very tight parameter distribution - high ruggedness, temperature stable behavior - very high switching speed Positive temperature coefficient in VCE(sat) PG-TO263-3-2 Low EMI Low Gate Charge Pb-free lead plating; RoHS compliant Qualified according to JEDEC1 for target applications Complete product spectrum and PSpice Models : http://www.infineon.com/igbt/ Type VCE IC VCE(sat),Tj=25C Tj,max Marking Code PackageIGB15N60T 600V 15A 1.5V G15T60 PG-TO263-3-2175C Maximum Ra
