irf1503pbf.pdf datasheet:
PD-95438AIRF1503PbFTypical ApplicationsHEXFET Power MOSFET Industrial Motor DriveDVDSS = 30VFeatures Advanced Process Technology Ultra Low On-ResistanceRDS(on) = 3.3mG 175C Operating Temperature Fast SwitchingID = 75A Repetitive Avalanche Allowed up to TjmaxSDescriptionThis design of HEXFET Power MOSFETs utilizesthe lastest processing techniques to achieve extremelylow on-resistance per silicon area. Additional featuresof this HEXFET power MOSFET are a 175C junctionoperating temperature, fast switching speed andimproved repetitive avalanche rating. These combineto make this design an extremely efficient and reliabledevice for use in a wide variety of applications.TO-220ABAbsolute Maximum RatingsParameter Max. UnitsID @ TC = 25C Continuous Drain Current, VGS @ 10V (Silicon limited) 240ID @ TC = 100C Continuous D
