irf2807s.pdf datasheet:

irf2807sirf2807s

Isc N-Channel MOSFET Transistor IRF2807SFEATURESWith To-263(D2PAK) packageLow input capacitance and gate chargeLow gate input resistance100% avalanche testedMinimum Lot-to-Lot variations for robust deviceperformance and reliable operationAPPLICATIONSSwitching applicationsABSOLUTE MAXIMUM RATINGS(T =25)aSYMBOL PARAMETER VALUE UNITV Drain-Source Voltage 75 VDSSV Gate-Source Voltage 20 VGSSDrain Current-ContinuousTc=2582I AD58Tc=100I Drain Current-Single Pulsed 280 ADMP Total Dissipation @T =25 230 WD CT Max. Operating Junction Temperature 175 chStorage Temperature -55~175 TstgTHERMAL CHARACTERISTICSSYMBOL PARAMETER MAX UNIT/WRth(ch-c) Channel-to-case thermal resistance 0.65/WRth(ch-a) Channel-to-ambient thermal resistance 401isc websitewww.iscsemi.cn isc & iscse
