irf5305str.pdf datasheet:
IRF5305STRwww.VBsemi.twP-Channel 60 V (D-S) MOSFETFEATURESPRODUCT SUMMARY Halogen-free According to IEC 61249-2-21VDS (V) RDS(on) () Max. ID (A) Qg (Typ.)Definition TrenchFET Power MOSFET0.048at VGS = - 10 V- 35- 60 60 100 % Rg and UIS Tested0.060at VGS = - 4.5 V - 30 Compliant to RoHS Directive 2002/95/ECAPPLICATIONSS Power Switch Load Switch in High Current ApplicationsD2PAK (TO-263) DC/DC ConvertersGDGDSP-Channel MOSFETABSOLUTE MAXIMUM RATINGS (TC = 25 C, unless otherwise noted)Parameter Symbol Limit UnitVDSDrain-Source Voltage - 60VVGSGate-Source Voltage 20TC = 25 C- 35Continuous Drain Current (TJ = 150 C) IDTC = 70 C- 30AIDMPulsed Drain Current (t = 300 s) - 100IASAvalanche Current - 32L = 0.1 mH EAS51 mJSingle Avalanche EnergyaTC = 25 C61bPD
