irfr214pbf irfu214pbf sihfr214 sihfu214.pdf datasheet:

IRFR214, IRFU214, SiHFR214, SiHFU214www.vishay.comVishay SiliconixPower MOSFETFEATURESPRODUCT SUMMARY Dynamic dV/dt RatingVDS (V) 250 Repetitive Avalanche RatedRDS(on) ()VGS = 10 V 2.0 Surface Mount (IRFR214, SiHFR214) Straight Lead (IRFU214, SiHFU214)Qg (Max.) (nC) 8.2 Available in Tape and ReelQgs (nC) 1.8 Fast SwitchingQgd (nC) 4.5 Ease of ParallelingConfiguration Single Material categorization: For definitions ofcompliance please see www.vishay.com/doc?99912 DDESCRIPTIONDPAK IPAKThird generation power MOSFETs from Vishay provide the(TO-252) (TO-251)designer with the best combination of fast switching,DDGruggedized device design, low on-resistance andcost-effectiveness.The DPAK is designed for surface mounting using vaporSG SDphase, infrared, or wave soldering techniques. The straight
