irg7ph46ud-e.pdf datasheet:

IRG7PH46UDPbFIRG7PH46UD-EPINSULATED GATE BIPOLAR TRANSISTOR WITHULTRAFAST SOFT RECOVERY DIODEFeaturesC Low VCE (ON) trench IGBT technologyVCES = 1200V Low switching losses Square RBSOAI NOMINAL = 40A 100% of the parts tested for ILM Positive VCE (ON) temperature co-efficientG TJ(max) = 150C Ultra fast soft recovery co-pak diode Tight parameter distributionEVCE(on) typ. = 1.7V Lead-Freen-channelBenefits High efficiency in a wide range of applications Suitable for a wide range of switching frequencies due toCClow VCE (ON) and low switching losses Rugged transient performance for increased reliability Excellent current sharing in parallel operationEApplications ECCGG U.P.S.TO-247AC TO-247AD WeldingIRG7PH46UDPbF IRG7PH46UD-EP Solar InverterG C E Induction Hea
