irgb4630dpbf irgib4630dpbf irgp4630dpbf irgs4630dpbf.pdf datasheet:

IR IGBT IRGB4630DPbF IRGIB4630DPbF IRGP4630D(-E)PbF IRGS4630DPbF Insulated Gate Bipolar Transistor with Ultrafast Soft Recovery Diode VCES = 600V C C C IC = 30A, TC =100C tSC 5s, TJ(max) = 175C E C E E G C G C G VCE(ON) typ. = 1.65V @ IC = 18A IRGP4630DPbF IRGP4630D-EPbF IRGB4630DPbF TO-247AC TO-247AD TO-220AB CC Applications Industrial Motor Drive E Inverters E C C G GG UPS Welding IRGS4630DPbF EIRGIB4630DPbF D2Pak TO-220AB Full-Pak n-channelG C EGate Collector EmitterFeatures Benefits High efficiency in a wide range of applications and switching Low VCE(ON) and switching losses frequencies Improved reliability due to rugged hard switching Square RBSOA and maximum junction temperature 175C performance and high power capability Positive VCE (ON) temperature coef
