jng40t65huy2.pdf datasheet:

JNG40T65HUY2 IGBT Features 650V,40A V =1.8V@V =15V,I =40A CE(sat)(typ.) GE C High speed switching Higher system efficiency Soft current turn-off waveforms Square RBSOA General Description JIAEN FS IGBTs offer lower losses and higher energy efficiency for application such as IH (induction heating),UPS, general inverter and other soft switching applications. Absolute Maximum Ratings Symbol Parameter Value Units V Collector-Emitter Voltage 650 V CESV Gate-Emitter Voltage + 30 V GES Continuous Collector Current ( T =25 ) 80 A CI C Continuous Collector Current ( T =100) 40 A CI Pulsed Collector Current (Note 1) 120 A CM I Diode Continuous Forward Current ( T =100 ) 40 A F CI Diode Maximum Forward Current (Note 1) 120 A FMt Short Circuit Withstand Time 5 us sc Maximum Power Dissipation ( T =
