ksa1013.pdf datasheet:
KSA1013Color TV Audio OutputColor TV Vertical Deflection OutputTO-92L11. Emitter 2. Collector 3. BasePNP EPITAXIAL SILICON TRANSISTORAbsolute Maximum Ratings Ta=25C unless otherwise noted Symbol Parameter Ratings UnitsVCBO Collector-Base Voltage -160 VVCEO Collector-Emitter Voltage -160 VVEBO Emitter-Base Voltage -6 VIC Collector Current -1 AIB Base Current -0.5 APC Collector Power Dissipation 900 mWTJ Junction Temperature 150 CTSTG Storage Temperature -55 ~ 150 CElectrical Characteristics Ta=25C unless otherwise noted Symbol Parameter Test Condition Min. Typ. Max. UnitsICBO Collector Cut-off Current VCB= -150V, IE=0 -1 AIEBO Emitter Cut-off Current VEB= -6mA, IC=0 -1 ABVCEO Collector-Emitter Breakdown Voltage IC= -10mA, IB=0 -160 VhFE DC Current Gain VCE= -5V, IC= -200mA 60 320VCE (sat) Collector-Emitter Saturation Voltage IC=
