mcq15n10y.pdf datasheet:

mcq15n10ymcq15n10y

MCQ15N10YFeatures Split Gate Trench MOSFET Technology Low Gate Charge Halogen Free Epoxy Meets UL 94 V-0 Flammability Rating N-CHANNEL Lead Free Finish/RoHS Compliant ("P" Suffix Designates RoHSCompliant. See Ordering Information)MOSFETMaximum Ratings Operating Junction Temperature Range : -55C to +150C Storage Temperature Range: -55C to +150C Thermal Resistance: 62.5C/W Junction to Ambient (1)SOP-8Parameter Symbol Rating UnitBDDrain-Source Voltage VDS 100 VGate-Source Volltage VGS 20 VACContinuous Drain Current ID 15 AFIDM 36 APulsed Drain Current (2) ETotal Power Dissipation PD 2 WKEAS 45 mJSingle Pulsed Avalanche Energy(3)Note: H J1. Surface Mounted on 1 in2 pad area, t 10 sec.2. Pulse Test: Pulse Width10s,Duty Cycle 1%.3. TJ=25C, L=0.1mH, VDD=50V. GDIMENSIONSINCHES
