mdf15n60gth mdp15n60gth.pdf datasheet:

mdf15n60gth_mdp15n60gthmdf15n60gth_mdp15n60gth

MDP15N60G / MDF15N60G N-Channel MOSFET 600V, 15A, 0.40 General Description Features These N-channel MOSFET are produced using advanced V = 600V DSMagnaChips MOSFET Technology, which provides low on- I = 15A @ V = 10V D GSstate resistance, high switching performance and excellent R 0.40 @ V = 10V DS(ON) GSquality. Applications These devices are suitable device for SMPS, high Speed switching and general purpose applications. Power Supply PFC High Current, High Speed Switching DGTO-220 TO-220F MDP Series MDF Series SAbsolute Maximum Ratings (Ta = 25oC) Characteristics Symbol MDP15N60G MDF15N60G Unit Drain-Source Voltage VDSS 600 V Gate-Source Voltage VGSS 30 V TC=25oC 15 15* A Continuous Drain Current ID TC=100oC 9.5 9.5* A Pulsed Drain Current(2) IDM 60 60* A TC=25oC 231.4 36.7 W Po
