mdp10n60gth.pdf datasheet:

mdp10n60gthmdp10n60gth

INCHANGE Semiconductorisc N-Channel MOSFET Transistor MDP10N60GTHFEATURESWith TO-220F packagingHigh speed switchingVery high commutation ruggednessEasy to use100% avalanche testedMinimum Lot-to-Lot variations for robust deviceperformance and reliable operationzAPPLICATIONSPFC stagesLCD & PDP TVPower supplySwitching applicationsABSOLUTE MAXIMUM RATINGS(T =25)aSYMBOL PARAMETER VALUE UNITV Drain-Source Voltage 600 VDSSV Gate-Source Voltage 30 VGSSDrain Current-Continuous@T =25C 10I AD6.3T =100CI Drain Current-Single Pulsed 40 ADMP Total Dissipation 48 WDT Operating Junction Temperature -55~150 jStorage Temperature -55~150 TstgTHERMAL CHARACTERISTICSSYMBOL PARAMETER MAX UNIT/WRth(ch-c) Channel-to-case thermal resistance 2.6/WRth(ch-a) Channel-to-ambient
