mmbta05 mmbta06 mmbta55 mmbta56.pdf datasheet:

PMMBTA05 / MMBTA06 / MMBTA55 / MMBTA56 NPN AND PNP HIGH VOLTAGE TRANSISTOR SOT-23 Unit: inch(mm) 60~80V 225mW Voltage Power Features NPN and PNP silicon, planar design Collector current IC = 500mA Lead free in compliance with EU RoHS 2.0 Green molding compound as per IEC 61249 standard Mechanical Data Case: SOT-23 Package Terminals: Solderable per MIL-STD-750, Method 2026 Approx. Weight: 0.0003 ounces, 0.0084 grams oMaximum Ratings and Thermal Characteristics (TA=25 C unless otherwise noted) PARAMETER SYMBOL MMBTA05 MMBTA55 MMBTA06 MMBTA56 UNITS Marking B05 B55 B06 B56 Collector-Emitter Voltage VCEO 60 80 V Collector-Base Voltage VCBO 60 80 V Emitter-Base Voltage VEBO 4 V Collector Current-Continuous IC 500 mA Circuit Figure NPN PNP NPN PNP oMaximum Ratings and Thermal Characteristics (TA=25 C unless otherw
