mmbtsc1815o mmbtsc1815y mmbtsc1815g mmbtsc1815l.pdf datasheet:

mmbtsc1815o_mmbtsc1815y_mmbtsc1815g_mmbtsc1815lmmbtsc1815o_mmbtsc1815y_mmbtsc1815g_mmbtsc1815l

MMBTSC1815 NPN Silicon Epitaxial Planar Transistor for switching and AF amplifier applications. The transistor is subdivided into four groups O, Y, G and L, according to its DC current gain. As complementary type the PNP transistor MMBTSA1015 is recommended. TO-236 Plastic Package OAbsolute Maximum Ratings (Ta = 25 C) Parameter Symbol Value UnitCollector Base Voltage VCBO 60 VCollector Emitter Voltage VCEO 50 V Emitter Base Voltage VEBO 5 VCollector Current IC 150 mA Base Current IB 50 mAPower Dissipation Ptot 200 mWOJunction Temperature Tj 150 C OStorage Temperature Range Tstg - 55 to + 150 C OCharacteristics at Tamb=25 C Parameter Symbol Min. Max. UnitDC Current Gain at VCE = 6 V, IC = 2 mA Current Gain Group O hFE 70 140 - Y hFE 120 240 - G hFE 200 400 - L hFE 350 700 - at VCE = 6 V, IC = 150 mA hFE 25 - - Collector
