mmg800k060u6en.pdf datasheet:
MMG800K060U6EN600V 800A IGBT ModuleMay 2015 Version 01 RoHS CompliantPRODUCT FEATURES IGBT3 CHIP(Trench+Field Stop technology) High short circuit capability,self limiting short circuit current VCE(sat) with positive temperature coefficient Fast switching and short tail current Free wheeling diodes with fast and soft reverse recovery Low switching losses 10K Gate Protected Resistance InsideAPPLICATIONS High Power Converters Medical applications Motion/servo control UPS systems/Wind Turbines UPS systems/Wind TurbinesIGBT-InverterABSOLUTE MAXIMUM RATINGS T =25C unless otherwise specifiedCSymbol Parameter/Test Conditions Values UnitVCES Collector Emitter Voltage TJ=25 600VVGES Gate Emitter Voltage 20TC=25 950IC DC Collector CurrentTC=60 800 AICM Repetitive Peak Collector Current tp=1
