mmgt10cb120xb6c.pdf datasheet:

mmgt10cb120xb6cmmgt10cb120xb6c

MMGT10CB120XB6C1200V 10A PIM ModuleNovember 2019 Version 01 RoHS CompliantPRODUCT FEATURES IGBT CHIP(Trench+Field Stop technology) Substrate for Low Thermal Resistance Low saturation voltage and positive temperature coefficient Fast switching and short tail current Free wheeling diodes with fast and soft reverse recovery Solder Contact Technology, Rugged mounting due to integrated Mounting clamps Temperature sense includedAPPLICATIONS AC motor control Motion/servo control Rectifier+Brake+Inverter Inverter and power suppliesIGBT-inverterABSOLUTE MAXIMUM RATINGS(T =25C unless otherwise specified)CSymbol Parameter/Test Conditions Values UnitVCES TJ=25 1200Collector Emitter VoltageVVGESGate Emitter Voltage 20TC=25, TJmax=175 19ICDC Collector CurrentTC=105, TJmax=175 10 AICMRepetiti
