mpsa56 mmbta56 pzta56.pdf datasheet:

mpsa56_mmbta56_pzta56mpsa56_mmbta56_pzta56

February 2006MPSA56/MMBTA56/PZTA56 PNP General Purpose AmplifierDescriptionThis device is designed for general purpose amplifierapplications at collector currents to 300mA. Sourcedfrom Process 73Absolute Maximum Ratings*TA = 25C unless otherwise specified.Parameter Symbol Value UnitCollector-Emitter Voltage VCES -80 VCollector-Base Voltage VCBO -80 VEmitter-Base Voltage VEBO -4.0 VCollector Current Continuous IC -500 mAOperating and Storage Junction Temperature Range TJ, TSTG -55 to +150 C*These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.Notes:1. These ratings are based on a maximum junction temperature of 150C.2. These are steady state limits. The factory should be consulted on applications involving pulsed or low duty cycle operations.3. All voltages (V) and currents (A) are n
