nce15td60bd nce15td60b nce15td60bf.pdf datasheet:

PbFreeProduct NCE15TD60BD,NCE15TD60B,NCE15TD60BF 600V, 15A, Trench FS II Fast IGBT General Description: Using NCE's proprietary trench design and advanced FS (Field Stop) second generation technology, the 600V Trench FSII IGBT offers superior conduction and switching performances, and easy parallel operation; Features Trench FSII Technology offering Very low V CE sat High speed switching Positive temperature coefficient in V CE sat Very tight parameter distribution High ruggedness, temperature stable behavior Schematic diagram Application Air Condition Inverters Motor drives Package Marking and Ordering Information Device Device Package Device Marking NCE15TD60BD TO-263 NCE15TD60BD NCE15TD60B TO-220 NCE15TD60B NCE15TD60BF TO-220F NCE15TD60BF TO-220F TO-220 TO-263 Absolute Maximum Rati
