nce65tf360d nce65tf360 nce65tf360f.pdf datasheet:

NCE65TF360D,NCE65TF360,NCE65TF360F N-Channel Super Junction Power MOSFET General Description The series of devices use advanced trench gate super V 650 V DSjunction technology and design to provide excellent RDS(ON) R 290 m DS(ON)TYPwith low gate charge. This super junction MOSFET fits the ID 11.5 A industrys AC-DC SMPS requirements for PFC, AC/DC power conversion, and industrial power applications. Features Optimized body diode reverse recovery performance Low on-resistance and low conduction losses Small package Ultra Low Gate Charge cause lower driving requirements 100% Avalanche Tested ROHS compliant Application Power factor correctionPFC Schematic diagram Switched mode power supplies(SMPS) Uninterruptible Power SupplyUPS LLC Half-bridge Package Marking And Ordering Information
