nce75td120btp.pdf datasheet:

Pb Free ProductNCE75TD120BTP1200V, 75A, Trench FS II Fast IGBTGeneral DescriptionUsing NCE's proprietary trench design and advanced FS (Field Stop) secondgeneration technology, the 1200V Trench FSII IGBT offers superior conduction andswitching performances, and easy parallel operation;Features Trench FSII Technology Offering Very low VCE(sat) High speed switching Positive temperature coefficient in VCE(sat) Very tight parameter distribution High ruggedness, temperature stable behaviorSchematic diagramApplication Inverters Motor drives ConverterPackage Marking and Ordering InformationDevice Device Package Device MarkingNCE75TD120BTP TO-247P NCE75TD120BTPTO-247PAbsolute Maximum Ratings (T =25C unless otherwise noted)CSymbol Parameter Value UnitsV Collector-Emitter Voltage 1200 VCESV Gate- Emitter Vo
