nce75td120vtp.pdf datasheet:

PbFreeProduct NCE75TD120VTP 1200V, 75A, Trench FS II Fast IGBT General Description: Using NCE's proprietary trench design and advanced FS (Field Stop) second generation technology, the 1200V Trench FSII IGBT offers superior conduction and switching performances, and easy parallel operation; Features Trench FSII Technology Offering Very low V CE(sat) High speed switching Positive temperature coefficient in V CE(sat) Very tight parameter distribution High ruggedness, temperature stable behavior Schematic diagram Application PV power Three-level Solar String Inverter UPS Package Marking and Ordering Information Device Device Package Device Marking NCE75TD120VTP TO-247P NCE75TD120VTP TO-247P Absolute Maximum Ratings (T =25C C unless otherwise noted) Symbol Parameter Value Units V Collector-Emitter
