ntmfs4c06n.pdf datasheet:
NTMFS4C06NMOSFET Power, Single,N-Channel, SO-8 FL30 V, 69 AFeatureswww.onsemi.com Low RDS(on) to Minimize Conduction Losses Low Capacitance to Minimize Driver Losses Optimized Gate Charge to Minimize Switching LossesV(BR)DSS RDS(ON) MAX ID MAX These Devices are Pb-Free, Halogen Free/BFR Free and are RoHS4.0 mW @ 10 VCompliant30 V 69 A6.0 mW @ 4.5 VApplications CPU Power Delivery DC-DC ConvertersD (5-8)MAXIMUM RATINGS (TJ = 25C unless otherwise stated)Parameter Symbol Value UnitDrain-to-Source Voltage VDSS 30 VG (4)Gate-to-Source Voltage VGS 20 VContinuous Drain TA = 25C ID 20.0 AS (1,2,3)Current RqJATA = 80C 14.9(Note 1)N-CHANNEL MOSFETPower Dissipation TA = 25C PD 2.55 WRqJA (Note 1)Continuous Drain TA = 25C ID 31.6 AMARKINGCurrent RqJA 10 sDIAGRAMTA = 80C 23.7(Note 1)D
