sd2100.pdf datasheet:

N-Channel Depletion ModeLateral DMOS FETLLCSD2100 / SST2100FEATURES DESCRIPTIONON Fast Switching . . . . . . . . . . . . . . . . . . . . . . . . . t 1.0ns The SD2100/SST2100 is a depletion mode DMOS lateral FETrss Low Capacitance . . . . . . . . . . . . . . . . . . . . . . . . . c 2pf that provides ultra high speed switching with very low Low R . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 capacitance. The product is available in TO-72 and surface ONmount SOT-143.APPLICATIONSORDERING INFORMATION Analog SwitchesPart Package Temperature Range AmplifiersSD2100 TO-72 -55oC to +125oCSST2100 SOT-143 -55oC to +125oCXSD2100 Sorted Chips in Carriers -55oC to +125oCCONNECTION DIAGRAMS3TO-7221 SOURCE32 DRAIN43 GATE 244 SUBSTRATE1143BOTTOM VIEW12DRAIN(2
