sd210de sd212de sd214de.pdf datasheet:

High-Speed AnalogN-Channel DMOS FETsSD210 / SD212 / SD214FEATURES DESCRIPTION High Input to Output Isolation . . . . . . . . . . . . . . . . 120dB The Calogic SD210 is a 30V analog switch driver without a Low On Resistance . . . . . . . . . . . . . . . . . . . . . . . . 30 Ohm built-in protection diode from gate to substrate for use with Low Feedthrough and Feedback Transients SD212 and SD214 DMOS analog switches. Low Capacitance: Input (Gate). . . . . . . . . . . . . . . . . . . . . . . . . . . 2.4pF typ. ORDERING INFORMATION Output. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.3pF typ.Part Package Temperature Range Feedback . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.3pF typ. No protection Diode from Gate to Substrate for VerySD210DE Hermetic TO-72 Package -55oC to +125oCHigh
