SKP15N60 SKW15N60Fast IGBT in NPT-technology with soft, fast recovery anti-parallel EmCon diode C 75% lower Eoff compared to previous generation combined with low conduction losses Short circuit withstand time 10 s GE Designed for: - Motor controls - Inverter NPT-Technology for 600V applications offers: - very tight parameter distribution - high ruggedness, temperature stable behaviour PG-TO-247-3 PG-TO-220-3-1 - parallel switching capability (TO-220AB) Very soft, fast recovery anti-parallel EmCon diode Pb-free lead plating; RoHS compliant Qualified according to JEDEC1 for target applications Complete product spectrum and PSpice Models : http://www.infineon.com/igbt/ Type VCE IC VCE(sat) Tj Marking PackageSKP15N60 600V 15A 2.3V K15N60 PG-TO-220-3-1 150C SKW15N60 600V 15A 2.3V K15N60 PG-TO-247-
