spa15n60cfd.pdf datasheet:

spa15n60cfdspa15n60cfd

INCHANGE SemiconductorIsc N-Channel MOSFET Transistor SPA15N60CFDFEATURESWith TO-220F packageLow input capacitance and gate chargeLow gate input resistanceReduced switching and conduction losses100% avalanche testedMinimum Lot-to-Lot variations for robust deviceperformance and reliable operationAPPLICATIONSSwitching applicationsABSOLUTE MAXIMUM RATINGS(T =25)aSYMBOL PARAMETER VALUE UNITV Drain-Source Voltage 600 VDSSV Gate-Source Voltage 30 VGSSDrain Current-Continuous @Tc=2513.4I AD8.4(V at 10V) Tc=100GSI Drain Current-Single Pulsed 33 ADMP Total Dissipation @T =25 34 WD CTj Max. Operating Junction Temperature 150 Storage Temperature -55~150 TstgTHERMAL CHARACTERISTICSSYMBOL PARAMETER MAX UNIT/WRth(ch-c) Channel-to-case thermal resistance 3.7/WRth(ch-a) Channe
