sqs481enw.pdf datasheet:

sqs481enwsqs481enw

SQS481ENWwww.vishay.comVishay SiliconixAutomotive P-Channel 150 V (D-S) 175 C MOSFETFEATURESPowerPAK 1212-8W Single TrenchFET power MOSFETDD8DD AEC-Q101 qualified d77DD66 100 % Rg and UIS tested55 Material categorization:for definitions of compliance please seewww.vishay.com/doc?999121122SS33 SSS44SS1GTop View Bottom ViewMarking Code: Q026GPRODUCT SUMMARYVDS (V) -150RDS(on) () at VGS = -10 V 1.095DID (A) -4.7P-Channel MOSFETConfiguration SinglePackage PowerPAK 1212-8WABSOLUTE MAXIMUM RATINGS (TC = 25 C, unless otherwise noted)PARAMETER SYMBOL LIMIT UNITDrain-source voltage VDS -150V Gate-source voltage VGS 20TC = 25 C -4.7Continuous drain current a IDTC = 125 C -2.75Continuous source current (diode conduction) a IS -8 APulsed drain curr
