ss8050.pdf datasheet:

SS8050 MOTNPN TRANSISTOR NPN NPN High Voltage Transistor SMD SS8050 NPN, BEC Transistor Polarity: NPN General Purpose Transistors Transistor pinout: BEC SOT-23 Package Marking Code: Y1 hFE: 100~200, 200~300 Ldeal for Medium Power Amplification and Switching Inner circuit SS8050 3 2 1. Base 2. Emitter 1 3. Coollector DEVICE MARKING: Y1 SOT-23 SOT-23 CLASSIFICATION OF hFE RANK L H RANGE 100~200 200~300 MAXIMUM RATINGS Symbol Rating Unit Characteristic VCEO Collector-Emitter Voltage - 25 VCBO Collector-Base Voltage - 40 V VEBO Emitter-Base Voltage -
