ss8050.pdf datasheet:

SS8050SOT-23 Plastic-Encapsulate Transistors SS8050 TRANSISTOR (NPN) FEATURES Complimentary to SS8550 MARKING:Y1 MAXIMUM RATINGS (TA=25 unless otherwise noted) Symbol Parameter Value Units VCBO Collector-Base Voltage - 40 V VCEO Collector-Emitter Voltage - 25 V VEBO Emitter-Base Voltage - 5 V IC Collector Current -Continuous 1.5 APC Collector Power Dissipation 0.625 WTj Junction Temperature 150 Tstg Storage Temperature -55-150 ELECTRICAL CHARACTERISTICS (Tamb=25unless otherwise specified) Parameter Symbol Test conditions MIN TYP MAX UNIT
