std2n105k5 stp2n105k5 stu2n105k5.pdf datasheet:

STD2N105K5, STP2N105K5, STU2N105K5N-channel 1050 V, 6 typ., 1.5 A MDmesh K5 Power MOSFETs in DPAK, TO-220 and IPAK packagesDatasheet - production dataFeaturesTAB3Order codes VDS RDS(on) max ID PTOT1STD2N105K5DPAKSTP2N105K5 1050 V 8 1.5 A 60 WTABSTU2N105K5TAB Industrys lowest RDS(on) x area Industrys best figure of merit (FoM)332211 Ultra low gate chargeIPAKTO-220 100% avalanche tested Zener-protectedFigure 1. Internal schematic diagramApplicationsD(2, TAB) Switching applicationsDescriptionG(1) These very high voltage N-channel Power MOSFETs are designed using MDmesh K5 technology based on an innovative proprietary vertical structure. The result is a dramatic reduction in on-resistance and ultra-low gate charge for applications requiring superior power density and high ef
