std2n95k5 stf2n95k5 stp2n95k5 stu2n95k5.pdf datasheet:

STD2N95K5, STF2N95K5, STP2N95K5, STU2N95K5N-channel 950 V, 4.2 typ., 2 A Zener-protected SuperMESH 5 Power MOSFETs in DPAK, TO-220FP, TO-220 and IPAK packagesDatasheet - production dataFeaturesTABOrder codes VDS RDS(on) max ID PTOT31STD2N95K5 45 WDPAK3STF2N95K5 20 W21 950 V 5 2 ATABSTP2N95K5TO-220FP45 WSTU2N95K5TAB TO-220 worldwide best RDS(on)332 Worldwide best FOM (figure of merit)211 Ultra low gate chargeTO-220IPAK 100% avalanche tested Zener-protectedFigure 1. Internal schematic diagramD(2, TAB)Applications Switching applicationsDescriptionG(1)These N-channel Zener-protected Power MOSFETs are designed using STs revolutionary avalanche-rugged very high voltage SuperMESH 5 technology, based on an innovative proprietary vertical structure. The result is a drama
