sw10n70k swf10n70k swd10n70k.pdf datasheet:

SW10N70K N-channel Enhanced mode TO-220F/TO-252 MOSFET Features TO-220F TO-252 BVDSS : 700V ID : 10A High ruggedness Low RDS(ON) (Typ 0.36)@VGS=10V RDS(ON) : 0.36 Low Gate Charge (Typ 29nC) Improved dv/dt Capability 2 1 100% Avalanche Tested 1 2 2 3 3 Application:Charge,LED,TV-Power 1 1. Gate 2. Drain 3. Source General Description 3 This power MOSFET is produced with super junction advanced technology of SAMWIN. This technology enable the power MOSFET to have better characteristics, including fast switching time, low on resistance, low gate charge and especially excellent avalanche characteristics. Order Codes Item Sales Type Marking Package Packaging 1 SW F 10N70K SW10N70K TO-220F TUBE 2 SW D 10N70K SW10N70K TO-252 REEL Absolute maximum ratings Value Symbol Parameter Unit TO-220F TO-25
