tip36 tip36a tip36b tip36c.pdf datasheet:

Inchange Semiconductor Product Specification Silicon PNP Power Transistors TIP36/36A/36B/36C DESCRIPTION With TO-3PN package Complement to type TIP35/35A/35B/35C DC current gain hFE=25(Min)@IC=-1.5A APPLICATIONS Designed for use in general purpose power amplifier and switching applications. PINNING PIN DESCRIPTION1 Base Collector;connected to 2 mounting base Fig.1 simplified outline (TO-3PN) and symbol 3 EmitterAbsolute maximum ratings(Ta=) SYMBOL PARAMETER CONDITIONS VALUE UNITTIP36 -40TIP36A -60VCBO Collector-base voltage Open emitter V TIP36B -80TIP36C -100 TIP36 -40TIP36A -60VCEO Collector-emitter voltage Open base V TIP36B -80TIP36C -100 VEBO Emitter-base voltage Open collector -5 V IC Collector current -25 A ICM Collector current-peak -40 A IB Base current -5 APC Collector power dissipation TC=25 125
