tip36c.pdf datasheet:

UNISONIC TECHNOLOGIES CO., LTD TIP36C PNP SILICON TRANSISTOR HIGH POWER TRANSISTORS DESCRIPTION The UTC TIP36C is a PNP Expitaxial-Base transistor, designed for using in general purpose amplifier and switching applications. Complement to TIP35C. INTERNAL SCHEMATIC DIAGRAM C (2)(1)BE (3) ORDERING INFORMATION Order Number Pin Assignment Package Packing Lead Free Halogen Free 1 2 3 TIP36CL-x-T3P-T TIP3CG-x-T3P-T TO-3P B C E TubeTIP36CL-x-T3N-T TIP3CG-x-T3N-T TO-3PN B C E Tubewww.unisonic.com.tw 1 of 4 Copyright 2013 Unisonic Technologies Co., Ltd QW-R214-014.C TIP36C PNP SILICON TRANSISTOR ABSOLUTE MAXIMUM RATINGS PARAMETER SYMBOL RATINGS UNITCollector-Base Voltage (IE = 0) VCBO -100 VCollector-Emitter Voltage (IB = 0) VCEO -100 VEmitter-Base Voltage (IC = 0) VEBO -5 VCollector Current IC -25 ACollector Peak Current
