   Número de Parte: AP50G60W-HF
   Tipo de transistor: IGBT
   Polaridad de transistor: N

ESPECIFICACIONES TECNICAS


   Pcⓘ - Máxima potencia disipada: 277 W
   |Vce|ⓘ - Tensión máxima colector-emisor: 600 V
   |Vge|ⓘ - Tensión máxima puerta-emisor: 30 V
   |Ic|ⓘ - Colector de Corriente Continua a 25℃: 75 A
   |VCEsat|ⓘ - Voltaje de saturación colector-emisor, typ: 3.3 V @25℃
   |VGEth|ⓘ - Tensión máxima de puerta-umbral: 7 V
   Tjⓘ - Temperatura máxima de unión: 150 ℃
   trⓘ - Tiempo de subida, typ: 80 nS
   Coesⓘ - Capacitancia de salida, typ: 160 pF
   Qgⓘ - Carga total de la puerta, typ: 66 nC
   Paquete / Cubierta: TO247


 Búsqueda de reemplazo de AP50G60W-HF IGBT

   - Selección ⓘ de transistores por parámetros



AP50G60W-HF Datasheet (PDF)

 ..1. Size:95K  ape
 ap50g60w-hf.pdf pdf_icon

AP50G60W-HF

AP50G60W-HFHalogen-Free ProductAdvanced Power N-CHANNEL INSULATED GATEElectronics Corp. BIPOLAR TRANSISTORFeaturesC High Speed Switching VCES 600V Low Saturation Voltage IC 40AVCE(sat),Typ.=2.5V@IC=40A RoHS Compliant & Halogen-FreeGCCTO-3PGEEAbsolute Maximum RatingsSymbol Parameter Rating UnitsVCES Collector-Emitter Voltage 600 VVGE Gate-Emitter

 7.1. Size:95K  ape
 ap50g60sw.pdf pdf_icon

AP50G60W-HF

AP50G60SWRoHS-compliant ProductAdvanced Power N-CHANNEL INSULATED GATEElectronics Corp. BIPOLAR TRANSISTORFeaturesVCES 600VC High Speed Switching IC 45A Low Saturation VoltageVCE(sat),Typ.=2.6V@IC=33A CG Built-in Fast Recovery DiodeC TO-3PGEEAbsolute Maximum RatingsSymbol Parameter Rating UnitsVCES Collector-Emitter Voltage 600 VVGE Gate-Emitter Vo

 7.2. Size:96K  ape
 ap50g60sw-hf.pdf pdf_icon

AP50G60W-HF

AP50G60SW-HFHalogen-Free ProductAdvanced Power N-CHANNEL INSULATED GATEElectronics Corp. BIPOLAR TRANSISTORFeaturesVCES 600VC High Speed Switching IC 45A Low Saturation VoltageVCE(sat),Typ.=2.6V@IC=33A CG Built-in Fast Recovery DiodeC TO-3PG RoHS Compliant & Halogen-FreeEEAbsolute Maximum RatingsSymbol Parameter Rating UnitsVCES Collector-Emitte

 9.1. Size:61K  ape
 ap50gt60sw-hf.pdf pdf_icon

AP50G60W-HF

AP50GT60SW-HFHalogen-Free ProductAdvanced Power N-CHANNEL INSULATED GATEElectronics Corp. BIPOLAR TRANSISTORFeaturesCVCES 600V High Speed Switching IC 45A Low Saturation VoltageVCE(sat),Typ.=1.85V@IC=45A CGC TO-3P Built-in Fast Recovery DiodeEG RoHS Compliant & Halogen-FreeEAbsolute Maximum RatingsSymbol Parameter Rating UnitsVCES Collector-Emit
