IRF7805 MOSFET. Datasheet. Equivalente. Reemplazo. Hoja de especificaciones. Principales características

   Número de Parte: IRF7805
   Tipo de FET: MOSFET
   Polaridad de transistor: N

ESPECIFICACIONES MÁXIMAS

   Pdⓘ - Máxima disipación de potencia: 2.5 W
   |Vds|ⓘ - Voltaje máximo drenador - fuente: 30 V
   |Vgs|ⓘ - Voltaje máximo fuente - puerta: 12 V
   |Id|ⓘ - Corriente continua de drenaje: 13 A
   Tjⓘ - Temperatura máxima de unión: 150 °C

CARACTERÍSTICAS ELÉCTRICAS

   |Vgs(th)|ⓘ - Tensión umbral entre puerta y fuente: 3 V
   Qgⓘ - Carga de la puerta: 22 nC
   trⓘ - Tiempo de subida: 20 nS
   Rds(on)ⓘ - Resistencia estado encendido drenaje a fuente: 0.011 Ohm
   Paquete / Cubierta: SO8

Búsqueda de reemplazo de MOSFET IRF7805

IRF7805 Datasheet (PDF)

..1. Size:236K international rectifier
irf7805 irf7805a.pdf

PD 91746CIRF7805/IRF7805AHEXFET Chip-Set for DC-DC Converters N Channel Application Specific MOSFETsA Ideal for Mobile DC-DC Converters 1 8S D Low Conduction Losses2 7S D Low Switching Losses3 6S DDescription4 5G DThese new devices employ advanced HEXFET PowerMOSFET technology to achieve an unprecedentedSO-8Top Viewbalance of on-resistan

..2. Size:236K international rectifier
irf7805.pdf

..3. Size:330K infineon
irf7805pbf.pdf

IRF7805PbF HEXFET Chip-Set for DC-DC Converters N Channel Application Specific MOSFETs A A1 8S D Ideal for Mobile DC-DC Converters 2 7S D Low Conduction Losses 3 6S D Low Switching Losses 4 5G D Lead-Free SO-8 Top ViewIRF7805PbF Description Devices Features This new device employs advanced HEXFET Power IRF7805PbF MOSFET technology to

0.1. Size:270K international rectifier
irf7805z.pdf

PD - 94635BIRF7805ZHEXFET Power MOSFETApplicationsVDSS RDS(on) maxQg (typ.)l High Frequency Point-of-Load6.8m:@VGS = 10V30V 18nCSynchronous Buck Converter forApplications in Networking &Computing Systems.AA1 8S DBenefits2 7S Dl Very Low RDS(on) at 4.5V VGS3 6S Dl Ultra-Low Gate Impedance45G Dl Fully Characterized Avalanche Voltage and Curr

0.2. Size:203K international rectifier
auirf7805q.pdf

PD 96367BAUIRF7805QFeaturesHEXFET Power MOSFETl Advanced Planar Technologyl Low On-ResistanceAAV(BR)DSS 30V1l Logic Level 8S Dl N Channel MOSFET2 7S DRDS(on) typ.9.2ml Surface Mount3 6S Dl Available in Tape & Reel4 5 max. 11ml 150C Operating Temperature G Dl Automotive [Q101] QualifiedTop View ID 13Al Lead-Free, RoHS CompliantD

0.3. Size:232K international rectifier
irf7805q.pdf

PD 96114IRF7805QPbFl Advanced Process Technologyl Ultra Low On-Resistancel N Channel MOSFETl Surface MountA1 8l Available in Tape & Reel S Dl 150C Operating Temperature2 7S Dl Automotive [Q101] Qualified3 6S Dl Lead-Free4 5G DDescriptionSO-8Top ViewSpecifically designed for Automotive applications, theseHEXFET Power MOSFET's in package utilize

0.4. Size:289K international rectifier
irf7805zgpbf.pdf

PD - 96253IRF7805ZGPbFHEXFET Power MOSFETApplicationsVDSS RDS(on) maxQg (typ.)l High Frequency Point-of-Load6.8m @VGS = 10V30V 18nC Synchronous Buck Converter for Applications in Networking & Computing Systems.Al Lead-FreeA1 8S Dl Halogen-Free2 7S D3 6BenefitsS Dl Very Low RDS(on) at 4.5V VGS 4 5G Dl Ultra-Low Gate ImpedanceSO-8Top Viewl

0.5. Size:270K infineon
irf7805zpbf.pdf

PD - 96011AIRF7805ZPbFHEXFET Power MOSFETApplicationsVDSS RDS(on) maxQg (typ.)l High Frequency Point-of-Load6.8m @VGS = 10V30V 18nCSynchronous Buck Converter forApplications in Networking &Computing Systems.Al Lead-FreeA1 8S DBenefits2 7S Dl Very Low RDS(on) at 4.5V VGS3 6S Dl Ultra-Low Gate Impedance4 5G Dl Fully Characterized Avalanche Vol

0.6. Size:2271K kexin
irf7805z.pdf

SMD Type MOSFETN-Channel Enhancement MOSFETIRF7805Z (KRF7805Z) FeaturesSOP-8 VDS (V) = 30V ID = 16 A (VGS = 10V) RDS(ON) 6.8m (VGS = 10V)A HEXFET Power MOSFET A1 81.50 0.15S D2 7S D3 6S D4 5G D Absolute Maximum Ratings Ta = 25Parameter Symbol Rating Unit Drain-Source Voltage VDS 30V Gate-Source Voltage VGS20 TA
