MTP4409H8 Todos los transistores



MTP4409H8 MOSFET. Datasheet. Equivalente. Reemplazo. Hoja de especificaciones. Principales características


   Número de Parte: MTP4409H8
   Tipo de FET: MOSFET
   Polaridad de transistor: P

ESPECIFICACIONES MÁXIMAS

   Pdⓘ - Máxima disipación de potencia: 50 W
   |Vds|ⓘ - Voltaje máximo drenador - fuente: 30 V
   |Vgs|ⓘ - Voltaje máximo fuente - puerta: 20 V
   |Id|ⓘ - Corriente continua de drenaje: 63 A
   Tjⓘ - Temperatura máxima de unión: 150 °C

CARACTERÍSTICAS ELÉCTRICAS


   trⓘ - Tiempo de subida: 18 nS
   Cossⓘ - Capacitancia de salida: 374 pF
   Rds(on)ⓘ - Resistencia estado encendido drenaje a fuente: 0.0073 Ohm
   Paquete / Cubierta: DFN5X6
     - Selección de transistores por parámetros



MTP4409H8 Datasheet (PDF)

 ..1. Size:284K  cystek
 mtp4409h8.pdf pdf_icon

MTP4409H8

Spec. No. : C808H8 Issued Date : 2013.09.02 CYStech Electronics Corp.Revised Date : Page No. : 1/8 P-Channel Logic Level Enhancement Mode Power MOSFET BVDSS -30VMTP4409H8ID -15A7.3m VGS=-10V, ID=-15A RDSON(TYP) 11m VGS=-4.5V, ID=-10A Description The MTP4409H8 is a P-channel enhancement-mode MOSFET, providing the designer with the best combination of fast swi

 7.1. Size:336K  cystek
 mtp4409q8.pdf pdf_icon

MTP4409H8

Spec. No. : C808Q8 Issued Date : 2012.04.03 CYStech Electronics Corp.Revised Date : 2014.05.16 Page No. : 1/9 P-CHANNEL ENHANCEMENT MODE POWER MOSFET BVDSS -30V MTP4409Q8 ID -15A RDSON@VGS=-10V, ID=-15A 7.7m(typ) RDSON@VGS=-4.5V, ID=-10A 11.4m(typ)Features Simple drive requirement Low on-resistance Fast switching speed Pb-free and Halogen-free

 8.1. Size:621K  cystek
 mtp4403sq8.pdf pdf_icon

MTP4409H8

Spec. No. : C804Q8 Issued Date : 2009.12.16 CYStech Electronics Corp.Revised Date : 2011.03.21 Page No. : 1/7 P-CHANNEL ENHANCEMENT MODE POWER MOSFET BVDSS -20VMTP4403SQ8 RDSON(MAX) 46m ID -6.1ADescription The MTP4403SQ8 is a P-channel enhancement-mode MOSFET, providing the designer with the best combination of fast switching, ruggedized device design, low on-resistan

 8.2. Size:622K  cystek
 mtp4403q8.pdf pdf_icon

MTP4409H8

Spec. No. : C791Q8 Issued Date : 2010.07.16 CYStech Electronics Corp.Revised Date : 2011.03.21 Page No. : 1/7 P-CHANNEL ENHANCEMENT MODE POWER MOSFET BVDSS -30VMTP4403Q8 RDSON(MAX) 50m ID -6.1ADescription The MTP4403Q8 is a P-channel enhancement-mode MOSFET, providing the designer with the best combination of fast switching, ruggedized device design, low on-resistance
