AOWF12N50 Todos los transistores



AOWF12N50 MOSFET. Datasheet. Equivalente. Reemplazo. Hoja de especificaciones. Principales características

Número de Parte: AOWF12N50

Tipo de FET: MOSFET

Polaridad de transistor: N

ESPECIFICACIONES MÁXIMAS

Disipación total del dispositivo (Pd): 28 W

Tensión drenaje-fuente (Vds): 500 V

Tensión compuerta-fuente (Vgs): 30 V

Corriente continua de drenaje (Id): 12 A

Temperatura operativa máxima (Tj): 150 °C

CARACTERÍSTICAS ELÉCTRICAS

Tensión umbral compuerta-fuente Vgs(th): 4.5 V

Tiempo de elevación (tr): 69 nS

Conductancia de drenaje-sustrato (Cd): 167 pF

Resistencia drenaje-fuente RDS(on): 0.52 Ohm

Empaquetado / Estuche: TO-262F

Búsqueda de reemplazo de MOSFET AOWF12N50



AOWF12N50 Datasheet (PDF)

1.1. aowf12n50.pdf Size:281K _aosemi

AOWF12N50
AOWF12N50

AOW12N50/AOWF12N50 500V, 12A N-Channel MOSFET General Description Product Summary VDS The AOW12N50 & AOWF12N50 have been fabricated 600V@150℃ 12A using an advanced high voltage MOSFET process that is ID (at VGS=10V) designed to deliver high levels of performance and < 0.52Ω RDS(ON) (at VGS=10V) robustness in popular AC-DC applications.By providing low RDS(on), Ciss and Crss

3.1. aowf12n60.pdf Size:262K _aosemi

AOWF12N50
AOWF12N50

AOW12N60/AOWF12N60 600V,12A N-Channel MOSFET General Description Product Summary VDS The AOW12N60 & AOWF12N60 have been fabricated 700V@150℃ 12A using an advanced high voltage MOSFET process that is ID (at VGS=10V) designed to deliver high levels of performance and < 0.55Ω RDS(ON) (at VGS=10V) robustness in popular AC-DC applications.By providing low RDS(on), Ciss and Crss a

3.2. aowf12n65.pdf Size:240K _aosemi

AOWF12N50
AOWF12N50

AOW12N65/AOWF12N65 650V, 12A N-Channel MOSFET General Description Product Summary VDS 750V@150℃ The AOW12N65 & AOWF12N65 have been fabricated using an advanced high voltage MOSFET process that is ID (at VGS=10V) 12A designed to deliver high levels of performance and RDS(ON) (at VGS=10V) < 0.72Ω robustness in popular AC-DC applications.By providing low RDS(on), Ciss and Crss al
