AP4P052H MOSFET. Datasheet. Equivalente. Reemplazo. Hoja de especificaciones. Principales características

   Número de Parte: AP4P052H
   Tipo de FET: MOSFET
   Polaridad de transistor: P

ESPECIFICACIONES MÁXIMAS

   Pdⓘ - Máxima disipación de potencia: 25 W
   |Vds|ⓘ - Voltaje máximo drenador - fuente: 40 V
   |Vgs|ⓘ - Voltaje máximo fuente - puerta: 20 V
   |Id|ⓘ - Corriente continua de drenaje: 17 A
   Tjⓘ - Temperatura máxima de unión: 150 °C

CARACTERÍSTICAS ELÉCTRICAS

   |Vgs(th)|ⓘ - Tensión umbral entre puerta y fuente: 3 V
   Qgⓘ - Carga de la puerta: 11 nC
   trⓘ - Tiempo de subida: 18 nS
   Cossⓘ - Capacitancia de salida: 80 pF
   Rds(on)ⓘ - Resistencia estado encendido drenaje a fuente: 0.052 Ohm
   Paquete / Cubierta: TO252

Búsqueda de reemplazo de MOSFET AP4P052H

AP4P052H Datasheet (PDF)

..1. Size:68K ape
ap4p052h.pdf

AP4P052HHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% UIS Test D BVDSS -40V Simple Drive Requirement RDS(ON) 52m Fast Switching Characteristic ID -17AG RoHS Compliant & Halogen-FreeSDescriptionGAP4P052 series are from Advanced Power innovated design andDSsilicon process technology to achieve the lowes

7.1. Size:67K ape
ap4p052j.pdf

AP4P052JHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% UIS Test D BVDSS -40V Simple Drive Requirement RDS(ON) 52m Fast Switching Characteristic ID -17AG RoHS Compliant & Halogen-FreeSDescriptionAP4P052 series are from Advanced Power innovated design and GDSTO-251(J)silicon process technology to achieve

9.1. Size:176K ape
ap4p013les.pdf

AP4P013LESHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Low On-resistance D BVDSS -40V Simple Drive Requirement RDS(ON) 14.5m Fast Switching Characteristic ID -50AG RoHS Compliant & Halogen-FreeSDescriptionAP4P013LE series are from Advanced Power innovated design andsilicon process technology to achieve the lowe

9.2. Size:204K ape
ap4p012leh.pdf

AP4P012LEHHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Low On-resistance D BVDSS -40V Simple Drive Requirement RDS(ON) 13.5m Fast Switching Characteristic ID -51AG RoHS Compliant & Halogen-FreeSDescriptionAP4P012LE series are from Advanced Power innovated design and GDsilicon process technology to achieve the

9.3. Size:179K ape
ap4p016i.pdf

AP4P016IHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% UIS Test D BVDSS -40V Simple Drive Requirement RDS(ON) 16m Fast Switching Characteristic ID4 -36AG RoHS Compliant & Halogen-FreeSDescriptionAP4P016 series are from Advanced Power innovated design andsilicon process technology to achieve the lowest possib

9.4. Size:205K ape
ap4p016h.pdf

AP4P016HHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% UIS Test D BVDSS -40V Simple Drive Requirement RDS(ON) 16m Fast Switching Characteristic ID -45AG RoHS Compliant & Halogen-FreeSDescriptionGAP4P016 series are from Advanced Power innovated design andDSsilicon process technology to achieve the lowes

9.5. Size:164K ape
ap4p013lep.pdf

AP4P013LEPHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Low On-resistance D BVDSS -40V Simple Drive Requirement RDS(ON) 14.5m Fast Switching Characteristic ID -50AG RoHS Compliant & Halogen-FreeSDescriptionAP4P013LE series are from Advanced Power innovated design andsilicon process technology to achieve the lowe

9.6. Size:185K ape
ap4p018m.pdf

AP4P018MHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Low Gate Charge D BVDSS -40V Fast Switching Characteristic RDS(ON) 18m Simple Drive Requirement ID3 -9.4AG RoHS Compliant & Halogen-FreeSDescriptionDDAP4P018 series are from Advanced Power innovated design and siliconDDprocess technology to achieve th

9.7. Size:72K ape
ap4p016p.pdf

AP4P016PHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% UIS Test D BVDSS -40V Simple Drive Requirement RDS(ON) 16m Fast Switching Characteristic ID -45AG RoHS Compliant & Halogen-FreeSDescriptionAP4P016 series are from Advanced Power innovated design andsilicon process technology to achieve the lowest possibl
