AP6902GH-HF MOSFET. Datasheet. Equivalente. Reemplazo. Hoja de especificaciones. Principales características

   Número de Parte: AP6902GH-HF
   Tipo de FET: MOSFET
   Polaridad de transistor: N

ESPECIFICACIONES MÁXIMAS

   Pdⓘ - Máxima disipación de potencia: 3 W
   |Vds|ⓘ - Voltaje máximo drenador - fuente: 30 V
   |Vgs|ⓘ - Voltaje máximo fuente - puerta: 20 V
   |Id|ⓘ - Corriente continua de drenaje: 13 A
   Tjⓘ - Temperatura máxima de unión: 150 °C

CARACTERÍSTICAS ELÉCTRICAS

   |Vgs(th)|ⓘ - Tensión umbral entre puerta y fuente: 3 V
   Qgⓘ - Carga de la puerta: 10 nC
   trⓘ - Tiempo de subida: 44 nS
   Cossⓘ - Capacitancia de salida: 200 pF
   Rds(on)ⓘ - Resistencia estado encendido drenaje a fuente: 0.01 Ohm
   Paquete / Cubierta: SDPAK

Búsqueda de reemplazo de MOSFET AP6902GH-HF

AP6902GH-HF Datasheet (PDF)

..1. Size:95K ape
ap6902gh-hf.pdf

AP6902GH-HFPreliminaryAdvanced Power DUAL N-CHANNEL ENHANCEMENTElectronics Corp. MODE POWER MOSFET Simple Drive Requirement BVDSS 30V Fast Switching Performance RDS(ON) 10m Two Independent Device ID 42A Halogen Free & RoHS Compliant ProductDescriptionAdvanced Power MOSFETs from APEC provide theD1 (TAB1)designer with the best combination of fast switching,D2

8.1. Size:94K ape
ap6902agh-hf.pdf

AP6902AGH-HFHalogen-Free ProductAdvanced Power DUAL N-CHANNEL ENHANCEMENTElectronics Corp. MODE POWER MOSFETD1 (TAB1) Simple Drive Requirement BVDSS 30VD2 (TAB2) Fast Switching Performance RDS(ON) 9.2m Two Independent Device ID 52AS1G1 Halogen Free & RoHS CompliantS2G2SDPAKTMDescriptionAdvanced Power MOSFETs from APEC provide the designerD2D1w

9.1. Size:127K ape
ap6900gsm-hf.pdf

AP6900GSM-HFHalogen-Free ProductAdvanced Power DUAL N-CHANNEL MOSFET WITHElectronics Corp. SCHOTTKY DIODES1/D2 Simple Drive Requirement CH-1 BVDSS 30VS1/D2S1/D2 DC-DC Converter Suitable RDS(ON) 30m G1 Fast Switching Performance ID 5.7AS2/A RoHS Compliant CH-2 BVDSS 30VG2D1D1SO-8RDS(ON) 22mDescription ID 9.8AAdvanced Power MOSFETs from APEC p

9.2. Size:59K ape
ap6907gh-hf.pdf

AP6907GH-HFHalogen-Free ProductAdvanced Power DUAL N-CHANNEL ENHANCEMENTElectronics Corp. MODE POWER MOSFET Simple Drive Requirement BVDSS 100V Fast Switching Performance RDS(ON) 150m Two Independent Device ID 9A Halogen Free & RoHS Compliant ProductD1 (TAB1)D2 (TAB2)DescriptionAdvanced Power MOSFETs from APEC provide thedesigner with the best combination o

9.3. Size:60K ape
ap6905gh-hf.pdf

AP6905GH-HFPreliminaryAdvanced Power DUAL N-CHANNEL ENHANCEMENTElectronics Corp. MODE POWER MOSFET Simple Drive Requirement BVDSS 40V Fast Switching Performance RDS(ON) 13m Two Independent Device ID 37A Halogen Free & RoHS Compliant ProductDescriptionAdvanced Power MOSFETs from APEC provide theD1 (TAB1)designer with the best combination of fast switching,D2

9.4. Size:128K ape
ap6901agsm-hf.pdf

AP6901AGSM-HFHalogen-Free ProductAdvanced Power DUAL N-CHANNEL MOSFET WITHElectronics Corp. SCHOTTKY DIODES1/D2 Simple Drive Requirement CH-1 BVDSS 30VS1/D2S1/D2 DC-DC Converter Suitable RDS(ON) 16.5m G1 Fast Switching Performance ID 7.4AS2/AG2 RoHS Compliant & Halogen-Free CH-2 BVDSS 30VD1D1SO-8RDS(ON) 16mDescription ID 9.3AAdvanced Power M

9.5. Size:89K ape
ap6901gsm-hf.pdf

AP6901GSM-HFHalogen-Free ProductAdvanced Power DUAL N-CHANNEL MOSFET WITHElectronics Corp. SCHOTTKY DIODES1/D2 Simple Drive Requirement CH-1 BVDSS 30VS1/D2S1/D2 DC-DC Converter Suitable RDS(ON) 16.5m G1 Fast Switching Performance ID 7.1AS2/AG2 RoHS Compliant & Halogen-Free CH-2 BVDSS 30VD1D1SO-8RDS(ON) 16mDescription ID 9.2AAdvanced Power MO

9.6. Size:119K ape
ap6900gh-hf.pdf

AP6900GH-HFPreliminaryAdvanced Power DUAL N-CHANNEL ENHANCEMENTElectronics Corp. MODE POWER MOSFET Simple Drive Requirement CH-1 BVDSS 30V Fast Switching Performance RDS(ON) 6.2m Two Independent Device ID 72A Halogen Free & RoHS Compliant Product CH-2 BVDSS 30VRDS(ON) 10mDescription ID 45AAdvanced Power MOSFETs from APEC provide theD1 (TAB1)designer with

9.7. Size:96K ape
ap6904gh-hf.pdf

AP6904GH-HFPreliminaryAdvanced Power DUAL N-CHANNEL ENHANCEMENTElectronics Corp. MODE POWER MOSFET Simple Drive Requirement BVDSS 30V Fast Switching Performance RDS(ON) 18m Two Independent Device ID 22A Halogen Free & RoHS Compliant ProductDescriptionAdvanced Power MOSFETs from APEC provide theD1 (TAB1)designer with the best combination of fast switching,D2

9.8. Size:134K ape
ap6900gsm.pdf

AP6900GSMPb Free Plating ProductAdvanced Power DUAL N-CHANNEL MOSFET WITHElectronics Corp. SCHOTTKY DIODES1/D2 Simple Drive Requirement CH-1 BVDSS 30VS1/D2S1/D2 DC-DC Converter Suitable RDS(ON) 30m G1 Fast Switching Performance ID 5.7AS2/ACH-2 BVDSS 30VG2D1SO-8RDS(ON) 22mD1Description ID 9.8AThe Advanced Power MOSFETs from APEC provide the D1

9.9. Size:95K ape
ap6906gh-hf.pdf

AP6906GH-HFPreliminaryAdvanced Power DUAL N-CHANNEL ENHANCEMENTElectronics Corp. MODE POWER MOSFET Simple Drive Requirement BVDSS 60V Fast Switching Performance RDS(ON) 40m Two Independent Device ID 16.4A Halogen Free & RoHS Compliant ProductD1 (TAB1)D2 (TAB2)DescriptionAdvanced Power MOSFETs from APEC provide thedesigner with the best combination of fast s

9.10. Size:95K ape
ap6903gh-hf.pdf

AP6903GH-HFPreliminaryAdvanced Power DUAL N-CHANNEL ENHANCEMENTElectronics Corp. MODE POWER MOSFET Simple Drive Requirement BVDSS 30V Fast Switching Performance RDS(ON) 12.5m Two Independent Device ID 32A Halogen Free & RoHS Compliant ProductDescriptionAdvanced Power MOSFETs from APEC provide theD1 (TAB1)designer with the best combination of fast switching,

9.11. Size:89K ape
ap6901gh-hf.pdf

AP6901GH-HFHalogen-Free ProductAdvanced Power DUAL N-CHANNEL ENHANCEMENTElectronics Corp. MODE POWER MOSFET Simple Drive Requirement BVDSS 30V Fast Switching Performance RDS(ON) 6.5m Two Independent Device ID 70A Halogen Free & RoHS Compliant ProductDescriptionAdvanced Power MOSFETs from APEC provide theD1 (TAB1)designer with the best combination of fast swit
