SLD80R500SJ Todos los transistores



SLD80R500SJ MOSFET. Datasheet. Equivalente. Reemplazo. Hoja de especificaciones. Principales características


   Número de Parte: SLD80R500SJ
   Tipo de FET: MOSFET
   Polaridad de transistor: N

ESPECIFICACIONES MÁXIMAS

   Pdⓘ - Máxima disipación de potencia: 83 W
   |Vds|ⓘ - Voltaje máximo drenador - fuente: 800 V
   |Vgs|ⓘ - Voltaje máximo fuente - puerta: 30 V
   |Id|ⓘ - Corriente continua de drenaje: 11 A
   Tjⓘ - Temperatura máxima de unión: 150 °C

CARACTERÍSTICAS ELÉCTRICAS

   |Vgs(th)|ⓘ - Tensión umbral entre puerta y fuente: 4.5 V
   Qgⓘ - Carga de la puerta: 38 nC
   trⓘ - Tiempo de subida: 60 nS
   Cossⓘ - Capacitancia de salida: 140 pF
   Rds(on)ⓘ - Resistencia estado encendido drenaje a fuente: 0.5 Ohm
   Paquete / Cubierta: TO252

 Búsqueda de reemplazo de MOSFET SLD80R500SJ



SLD80R500SJ Datasheet (PDF)

 ..1. Size:626K  maple semi
sld80r500sj slu80r500sj slp80r500sj slf80r500sj slb80r500sj sli80r500sj.pdf

SLD80R500SJ
SLD80R500SJ

SLD80R500SJ,SLU80R500SJ,SLP80R500SJ SLF80R500SJ, SLB80R500SJ, SLI80R500SJ 800V N-Channel MOSFET FeaturesGeneral Description Features -11A, 800V, RDS(on) typ.= 0.46@VGS = 10 V This Power MOSFET is produced using Maple semis Advanced Super-Junction technology. - Low gate charge ( typical 38nC) - 7.6A, 500V, RDS(on) typ. = 0.5@VGS = 10 VThis advanced technology has been

 8.1. Size:614K  maple semi
sld80r850sj slu80r850sj slp80r850sj slf80r850sj slb80r850sj sli80r850sj.pdf

SLD80R500SJ
SLD80R500SJ

SLD80R850SJ,SLU80R850SJ,SLP80R850SJ SLF80R850SJ, SLB80R850SJ, SLI80R850SJ 800V N-Channel MOSFET FeaturesGeneral Description Features -7A, 800V, RDS(on) typ.= 0.8@VGS = 10 V This Power MOSFET is produced using Maple semis Advanced Super-Junction technology. - Low gate charge ( typical 25nC) - 7.6A, 500V, RDS(on) typ. = 0.5@VGS = 10 VThis advanced technology has been es

 8.2. Size:1048K  maple semi
sld80r380sj slu80r380sj slp80r380sj slf80r380sj slb80r380sj sli80r380sj.pdf

SLD80R500SJ
SLD80R500SJ

SLD80R380SJ,SLU80R380SJ,SLP80R380SJ SLF80R380SJ, SLB80R380SJ, SLI80R380SJ 800V N-Channel MOSFET FeaturesGeneral Description Features -15A, 800V, RDS(on) typ.= 0.34@VGS = 10 V This Power MOSFET is produced using Maple semis Advanced Super-Junction technology. - Low gate charge ( typical 43nC) - 7.6A, 500V, RDS(on) typ. = 0.5@VGS = 10 VThis advanced technology has been
