SLF10N65A MOSFET. Datasheet. Equivalente. Reemplazo. Hoja de especificaciones. Principales características
Número de Parte: SLF10N65A
Tipo de FET: MOSFET
Polaridad de transistor: N
ESPECIFICACIONES MÁXIMAS
Máxima disipación de potencia (Pd): 32.1 W
Voltaje máximo drenador - fuente |Vds|: 650 V
Voltaje máximo fuente - puerta |Vgs|: 30 V
Corriente continua de drenaje |Id|: 10 A
Temperatura máxima de unión (Tj): 150 °C
CARACTERÍSTICAS ELÉCTRICAS
Tensión umbral entre puerta y fuente |Vgs(th)|: 4 V
Carga de la puerta (Qg): 19 nC
Tiempo de subida (tr): 30 nS
Conductancia de drenaje-sustrato (Cd): 138 pF
Resistencia entre drenaje y fuente RDS(on): 0.9 Ohm
Paquete / Cubierta: TO220F
Búsqueda de reemplazo de MOSFET SLF10N65A
SLF10N65A Datasheet (PDF)
slp10n65a slf10n65a.pdf
LEAD FREEPbRoHSSLP10N65A/SLF10N65A650V N-Channel MOSFETGeneral Description FeaturesThis Power MOSFET is produced using Maple semis - 10A, 650V, RDS(on)Typ = 0.745@VGS = 10 Vadvanced planar stripe DMOS technology. - Low gate charge ( typical 19nC)This advanced technology has been especially tailored - Low Crss ( typical 5.3pF)to minimize on-state resistance, provide superi
slp10n65c slf10n65c.pdf
SLP10N65C / SLF10N65C650V N-Channel MOSFETGeneral Description FeaturesThis Power MOSFET is produced using Maple semis - 10A, 650V, RDS(on) typ. = 0.678@VGS = 10 Vadvanced planar stripe DMOS technology. - Low gate charge ( typical 38nC)This advanced technology has been especially tailored - High ruggednessto minimize on-state resistance, provide superior switching - Fast switchi
slp10n65s slf10n65s.pdf
LEAD FREEPbRoHSSLP10N65S/ SLF10N65S650V N-Channel MOSFETGeneral Description FeaturesThis Power MOSFET is produced using Maple semis - 10A, 650V, RDS(on) typ=0.8@VGS = 10 Vadvanced planar stripe DMOS technology. - Low gate charge ( typical 28.5nC)This advanced technology has been especially tailored - High ruggednessto minimize on-state resistance, provide superior switchi
slp10n60c slf10n60c.pdf
SLP10N60C / SLF10N60C600V N-Channel MOSFETGeneral Description FeaturesThis Power MOSFET is produced using Maple semis - 10A, 600V, RDS(on)typ. = 0.62@VGS = 10 Vadvanced planar stripe DMOS technology. - Low gate charge ( typical 36.5nC)This advanced technology has been especially tailored - High ruggednessto minimize on-state resistance, provide superior switching - Fast switchi
