2N7002G-AE2-R Datasheet. Equivalente. Reemplazo. Hoja de especificaciones. Principales características
Número de Parte: 2N7002G-AE2-R 📄📄
Tipo de FET: MOSFET
Polaridad de transistor: N
ESPECIFICACIONES MÁXIMAS
Pdⓘ - Máxima disipación de potencia: 0.2 W
|Vds|ⓘ - Voltaje máximo drenador-fuente: 60 V
|Vgs|ⓘ - Voltaje máximo fuente-puerta: 20 V
|Id|ⓘ - Corriente continua de drenaje: 0.3 A
Tjⓘ - Temperatura máxima de unión: 150 °C
CARACTERÍSTICAS ELÉCTRICAS
Cossⓘ - Capacitancia de salida: 11 pF
RDSonⓘ - Resistencia estado encendido drenaje a fuente: 7.5 Ohm
Encapsulados: SOT-23
📄📄 Copiar
Búsqueda de reemplazo de 2N7002G-AE2-R MOSFET
- Selecciónⓘ de transistores por parámetros
2N7002G-AE2-R datasheet
