AP4959A Datasheet. Equivalente. Reemplazo. Hoja de especificaciones. Principales características
Número de Parte: AP4959A
Tipo de FET: MOSFET
Polaridad de transistor: P
ESPECIFICACIONES MÁXIMAS
Pdⓘ - Máxima
disipación de potencia: 3.1 W
|Vds|ⓘ - Voltaje máximo drenador-fuente: 30 V
|Vgs|ⓘ - Voltaje máximo fuente-puerta: 20 V
|Id|ⓘ - Corriente continua
de drenaje: 18 A
Tjⓘ - Temperatura máxima de unión: 150 °C
CARACTERÍSTICAS ELÉCTRICAS
trⓘ - Tiempo
de subida: 13 nS
Cossⓘ - Capacitancia de salida: 280 pF
RDSonⓘ - Resistencia estado encendido drenaje a fuente: 0.018 Ohm
Encapsulados: SOP8
Búsqueda de reemplazo de AP4959A MOSFET
- Selecciónⓘ de transistores por parámetros
AP4959A datasheet
..1. Size:1450K cn apm
ap4959a.pdf
AP4959A -30V P+P Channel Enhancement Mode MOSFET Description The AP4959A uses advanced trench technology to provide excellent R , low gate charge and DS(ON) operation with gate voltages as low as 4.5V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = -30V I =-18A DS D R
